Motion Control Projects


Some of the Projects

We have recently accomplished some complex motion control projects on 2-axis & 3-axis control applications.

  • Manufacturer of vacuum tubes at Bhajanpura, New Delhi.,
  • Profile generation for vacuum tubes implemented in fridges at 0.01 accuracy on Unitronics Motion controller & Fuji Servo system. 0.01 accuracy is not even provided by the Siemens PLC System presently installed at their site.,
  • System generates the required profile in 16 different steps with the desired accuracy as per the user input, and then provides the actual length by using the cutter on the Y-axis.,
  • Complete system is fully automated, requiring only user inputs on the HMI screen.,
  • Component production was increased by one tube in less than 20 seconds. Siemens system with 0.1 accuracy takes 18 seconds to do the same process.

Trampoline cum Jump Rope machine project on Motion Control System

The Below mentioned concept was designed by the Brainspree Infosystem Team in Conjunction with our automation team for a system to be installed all over world.

  • As the motion of the system is to be highly precise, being less than 1mm, and requiring sudden start/stop with immediate movements to and fro, their team decided to install a Servo Based System.,
  • At both ends, servos from Panasonic are installed which will be moving the trolley to and fro.,
  • A distinct pattern has to be followed, due to which Unitronics Motion controller is installed.,
  • Both Servo System movements are duly controlled by Unitronics motion controller to provide them with highly accurate movements in a pattern.,
  • Complete system works as a take-up and let-off system, turning by turn.

Controlling of stepper system

  • Stepper motor speed control system up to a maximum speed of 1600 RPM.
  • Stepper system will rotate a magnet which will act as a mixer to mix a powdered solvent.
  • Stepper RPM were controlled through a driver & Unitronics PLC system by giving pulses to the stepper.
  • System will have user-defined.
